4K Optical Hdmi Cable 60Hz HDR 4:4:4 Hdmi TO Micro HDMI Male to Male Audio Video Cable Ethernet HDMI Computer 18gbps

4K Optical Hdmi Cable 60Hz HDR 4:4:4 Hdmi TO Micro HDMI Male to Male Audio Video Cable Ethernet HDMI Computer 18gbps
  • Продавецpodemosregiondemurcia.info
  • Список ценUS $71.49piece
  • Продажная ценаUS $71.49piece
  • ДоставкаБесплатная доставка
  • Рейтинги4,3 (749)

Oписание продукта

HDMI 2.0 Active Optical Cable support HDR [email protected],18Gbps up to 100m maximum length

1.5m 2m 3m 5m 10m 15m 20m 25m 30m 40m 50m 60m 70m 80m 90m 100m 1080P 3D HDMI Cable ,support OEM

Specification:

- OD: 0.196"(5.0mm)
- HDMI Version: 2.0
- Bandwidth: 18.2Gbps
- HDMI Compliance: HDCP 2.2, EDID, CEC, Deep Color, ARC, 3D
- Resolutions: 4K (4096x2160/ 3840x2160)@60hz, [email protected], [email protected]
- ARC (Audio Return Channel): Handle audio return channel continuously.
- HDR(High Dynamic Range): Enables you to more brighter, detailed and true-to-life pictures
- No Additional Power Source: It doesn\'t require power source for this active cable
- Active HDMI Cords: Connect the correct end to your display (projector/tv) and the correct end to your source (Blu-ray player, HDMI out on AVR, etc)

Why Fiber HDMI Cable?
1. When copper cable can\'t carry full 4K signal over increasingly longer distances, our fiber optic HDMI 2.0 cable guarantees 18.2Gbps bandwidth to display 4K/60Hz HDR perfectly at Chroma Subsampling 4:4:4/ 4:2:2/ 4:2:0.

2. With 4K image supported as well as 32 audio channels, this cable delivers more high definition images and high fidelity audio, offering you a optimal experience such as PS4/Xbox 4K gaming.



DESCRIPTIONS:
Our HDMI Active Hybrid Cable is the most competitive long reach HDMI interconnection solution on the market. It supports HDMI Maximum Data Rate 6Gbps with light weight, flexible and ultra-small long-term bending radius (52mm) hybrid cable. With ouradvanced optical engine embedded. This HDMI Hybrid Cable provides full HDMI signal integrity, support up to 100m maximum length, plug and play. No external power required.

KEY FEATURES
◆ Up to 100m Maximum Length.(Custom Length Available)
◆ Low Power Consumption: 250mW (max). (Power Required)
◆ Plug and Play
◆ Compatible with HDMI 2.0 standard.
◆ Support HDCP
◆ Self-detecting function for EDID information
◆ No loss of signal - delivering crystal clear digital images instantly.
◆ Supports computer resolutions to 1080P and 4K2K(60P).
◆ Hybrid optical cable with fiber and copper wire

Applications:
◆ Digital Signage
◆ LED signboards in streets and in stadiums
◆ Medical Imaging Equipment
◆ Airplane On-board Video System
◆ Home Theater
◆ Blue-ray, 3D video, Projector, Set-up box, DVR, Game Consoles and Computer
◆ TV Broadcast Station
◆ Conference Room Video Equipment
◆ Security systems


Item

Description

Units

Transmitter (Source)

Receiver (Sink)

HDCP & DDC

HDCP 2.0 Fully Support bi-directional EDID and HDCP communication

Video Bandwidth

6 Gbps/x3Channel (max)+ Clock.

Supported

Resolution & Distance

PC: WUXGA 1920 x 1200 up to 100 meters,HDTV : 480p, 720p, 1080i and 1080p deep color, 4K(60P), 3DFull HD 1920 x 1080 up to 100 meters

O/E Converter

4 channel 850 nm VCSEL array

4 CH GaAs PD array

Connector Type

HDMI type A

Cable Type

Hybrid type with OM3 fiber and copper wire

Cable Length

1.5m-10m/15m/20m/30m/40m/50m/60m/70m/80m/90m/100m (with +/-30cm tolerance) Custom length available.

Cable Outer Diameter

4.0mm

Jacket Outer Material

PVC/TPE

Cable Weight  TBD

Cable Weight  TBD

Cable Color  TBD

Cable Color  TBD

Differential Input

100 ohm (typ)

Power Consumption

250mW (max)

Power Supply

No external power required
